BendCom® Bend-rezistans sèl-mòd fib G.657.A1-plis
Pèfòmans pwodwi
Pèfòmans ki ba-pèt ak pèfòmans koube-ensansib.
Fib yo disponib nan de dyamèt disponib: 245μm (estanda) / 200μm (opsyonèl).
Optimize MFD ak pwopriyete jeyometrik egzak.
Senaryo aplikasyon
Gigabit bande lakay ak FTTP, elatriye.
Pre-5konstriksyon rezo G, elatriye.
Sant done, entèkoneksyon òdinatè.
Spesifikasyon pwodwi
|
Karakteristik |
Kondisyon |
Inite yo |
Valè spesifye |
|
Karakteristik optik |
|||
|
Atténuation |
1310nm |
dB/km |
Mwens pase oswa egal a 0.350 |
|
1383nm |
dB/km |
Mwens pase oswa egal a 0.350 |
|
|
1550nm |
dB/km |
Mwens pase oswa egal a 0.210 |
|
|
1625nm |
dB/km |
Mwens pase oswa egal a 0.230 |
|
|
Chanjman atténuation relatif longèdonn |
1310nm VS. 1285-1330mn |
dB/km |
Mwens pase oswa egal a 0.04 |
|
1550nm VS. 1525-1575mn |
dB/km |
Mwens pase oswa egal a 0.03 |
|
|
Zewo Dispèsyon longèdonn (λ0) |
- |
nm |
1300-1324 |
|
Zewo dispèsyon pant |
- |
ps/nm2�% b7km |
Mwens pase oswa egal a 0.092 |
|
PMD |
- |
ps/√km |
Mwens pase oswa egal a 0.2 |
|
Longèdonn koupe kab (λjès) |
- |
nm |
Mwens pase oswa egal a 1260 |
|
Dyamèt jaden mòd (MFD) |
1310nm |
μm |
9.2±0.4 |
|
1550mn |
μm |
10.4±0.5 |
|
|
Diskontinuite atténuation |
1310nm |
dB |
Mwens pase oswa egal a 0.03 |
|
1550mn |
dB |
Mwens pase oswa egal a 0.05 |
|
|
Karakteristik jewometrik |
|||
|
Dyamèt CLADDING |
μm |
125±0.7 |
|
|
Cladding ki pa-sikilarite |
% |
Mwens oswa egal a 1.0 |
|
|
Erè Konsantrisite Nwayo-Cladding |
μm |
Mwens pase oswa egal a 0.5 |
|
|
Dyamèt kouch |
μm |
242±7 |
|
|
200±10 |
|||
|
Erè Konsantrisite Coating-Cladding |
μm |
Mwens pase oswa egal a 12 |
|
|
Boukl (Radyo) |
m |
Pi gran pase oswa egal a 4 |
|
|
Karakteristik anviwònman 1550nm & 1625nm |
|||
|
Depandans Tanperati Enduit Atténuation |
-60 degre a +85 degre |
dB/km |
Mwens pase oswa egal a 0.05 |
|
Depandans chalè mouye pwovoke atténuation |
85 degre ak 85% RH, pou 30 jou |
dB/km |
Mwens pase oswa egal a 0.05 |
|
Watersoak Depandans Enduit Atténuation |
23 degre, pou 30 jou |
dB/km |
Mwens pase oswa egal a 0.05 |
|
Sèk chalè pwovoke atténuation |
85 degre, pou 30 jou |
dB/km |
Mwens pase oswa egal a 0.05 |
|
Pwopriyete mekanik |
|||
|
Depistaj tansyon |
- |
GPa |
0.69 |
|
- |
ksip |
100 |
|
|
Fòs bann kouvwi * |
pik fòs |
N |
1.3-8.9 |
|
tipik fòs mwayèn |
N |
1.0-5.0 |
|
|
Fòs rupture |
Pwobabilite Weber 50% |
Gpa |
Pi gran pase oswa egal a 4.00 |
|
Pwobabilite Weber 15% |
Gpa |
Pi gran pase oswa egal a 3.20 |
|
|
Paramèt Fatig dinamik (nd) |
- |
- |
Pi gran pase oswa egal a 20 |
|
Macro-bend atenuasyon pwovoke |
|||
|
Ø30mm × 10 |
1550nm |
dB |
Mwens pase oswa egal a 0.25 |
|
1625nm |
dB |
Mwens oswa egal a 1.0 |
|
|
Ø20mm × 1 |
1550nm |
dB |
Mwens pase oswa egal a 0.75 |
|
1625nm |
dB |
Mwens pase oswa egal a 1.5 |
|
|
*Nan yon dyamèt kouch 200±10, fòs dekale kouch nan pik nan 0.6-8.9 N ak mwayèn 0.6-5 .0 N |
|||
